USB

特長

あらゆるニーズにお応えできるよう、豊富なバリエーションを取り揃えています。

用途

情報通信機器、モバイルバッテリー、モニター

一般仕様

A/B 2.0A/B 3.0miniBMicroBC
定格 Rating1A  30V AC1A  30V AC1A  5V AC1A  30V AC30V AC /5A(Vbus)               /1.25A(Vconn, GND)  /0.25A(Others)
耐電圧　 Withstand voltage500V AC 1minute100V AC  1minute100V AC  1minute100V AC  1minute100V AC  1minute
絶縁抵抗 Insulation resistance500V DC   1000MΩMin100V DC    1000MΩMin100V DC    1000MΩMin100V DC    1000MΩMin100V DC    1000MΩMin
接触抵抗 Contact resistance30mΩMax (100mA Max)50mΩMax (100mA Max)50mΩMax (100mA Max)30mΩMax (100mA Max)40mΩMax (100mA Max)
挿抜寿命 Durability1,500 cycles1,500 cycles5,000 cycles10,000 cycles10,000 cycles
使用温度範囲 Practical temp-25℃～+70℃-25℃～+70℃-20℃～+60℃-20℃～+60℃-20℃～+60℃
品名外観品番
USB 3.2(Gen2)準拠 Type C
RA 24P		YKF45-0080N
USB 3.2(Gen2)準拠 Type C
RA 24P　Hhybrid Terminal		YKF45-0079N
USB 2.0準拠 Type C
RA 16P		YKF45-0076N
USB 2.0準拠 Type C
VT 16P		YKF45-0084N
USB 2.0準拠 MiniB
RA		YKF45-0037N
USB 2.0準拠 MicroB
RA		KF0101A05EK4
USB 2.0準拠 MicroB
RA Long terminal		YKF45-0078N
USB 2.0準拠 Type A
RA		YKF45-0033N
USB 2.0準拠 Type A
RA SMD(4P)		YKF45-0067N
USB 2.0準拠 Type A
UR		YKF45-0053N
USB 2.0準拠 Type A
RA DUAL		YKF45-0083N
USB 2.0準拠 Type B
RA		YKF45-0002N (WHT)
YKF45-0021N (BLK)
YKF45-0020N (with FLANGE)
USB 2.0準拠 Type B
VT		YKF45-0016P
USB 3.2(Gen1)準拠 Type A
RA		YKF45-0065N
USB 3.2(Gen1)準拠 Type A
UR		YKF45-0052N
USB 3.2(Gen1)準拠 Type A
VT		YKF45-0066N
USB 3.2(Gen1)準拠 Type B
RA		YKF45-0055N
